Aluminium Windows
SV-6000 Urban
System code SV-6000 ID·Thermal break
Price on requestGet a free quotation
The industrial aesthetics of the SV-6000 Urban, along with its excellent performance coefficients and the capability for large-scale constructions, make it a system that lends a unique…
- Thermal
- Uf from 2,0 W/m²K
- Glazing
- 29 mm
- System
- Thermal break
- Unique aesthetic character with industrial retro style, combined with clean design lines that give a modern touch.
- Standard with 24mm polyamide and Uf from 2.97 W/m²K
- An ideal choice for storefront facades with a retro style
- Capable of constructing large dimensions
Prefer to talk? +44 7426 890065or use the quick form below.
Free quotation · EN tested · 25-yr finish guarantee
CE Marked
UKCA
PAS 24
Qualicoat
01In detail
Overview
The industrial aesthetics of the SV-6000 Urban, along with its excellent performance coefficients and the capability for large-scale constructions, make it a system that lends a unique character to any space. It is available in two versions for different performance levels: the Advanced, for higher thermal insulation performance, and the Standard, which meets the requirements of KENAK.
The system has two major advantages. The first is its functional capabilities, as it can cover large surfaces. The internal dividers of the construction are equipped with reinforcement bars to support large dimensions, with a visible width of 4mm or 11mm. The second advantage is its industrial aesthetics, which make it unique for combining a retro look with high performance.
02Built in
Key characteristics
- Unique aesthetic character with industrial retro style, combined with clean design lines that give a modern touch.
- Minimalist features with:
- A slim perimeter frame of 35mm and a combination with the sash at 78mm
- The option to install a concealed sash opening mechanism with a 180° opening capability
- Minimal mullions (glazing bars) on the exterior of the glass, only 30mm wide, enhancing the industrial aesthetic
- Option to choose between two types of thermal insulation:
- A slim perimeter
- Advanced with 24mm polyamide. Uf from 2.57 W/m²K
- Standard with 24mm polyamide and Uf from 2.97 W/m²K
- An ideal choice for storefront facades with a retro style
- Capable of constructing large dimensions
- Perfectly combines with the SV-6000 Thermo opening system and the SV-5200 Facade curtain wall system
03Tested performance
Technical specification
Figures depend on configuration, size and glazing — your quotation includes values calculated for your exact specification.
- Aluminum alloy
- EN AW 6060 T6
- Hardness
- 12 Webster
- Minimum coating thickness
- 75 µm
- Profile thickness
- 1,3-4 mm
- Dimensional tolerances according to
- EN 12020-02
- Frame dimensions
- 88 mm x 35 mm
- Glass sash dimensions
- 78 mm x 59 mm
- Glazing thickness
- 29 mm
- Polyamide width
- 24 mm
- Frame thermal transmittance coefficient
- Uf from 2,0 W/m²K
- Maximum sash dimensions (WxH)
- 1000 mm x 2300 mm
- Maximum sash weight
- 120 kg
- Maximum door sash weight
- 120 kg
04Ways to build it
Construction types
05For specifiers
Section drawings
06Where it belongs
Applications & finishes
- Residential
- Commercial
- Renovation
- New Build
- Anthracite Grey
- Jet Black
- Traffic White
- Slate Grey
- Bronze Anodised
- Golden Oak
Every SIVAL system is finished to order: powder coating in any RAL shade (matt, satin or gloss), anodised tones, and textured wood-effect finishes including oak, walnut and rosewood. Dual-colour options let the interior differ from the exterior, and marine-grade pre-treatment is available for coastal sites. Powder-coated finishes are guaranteed for up to 25 years.
ask about this system
Price the SV-6000 Urban for your project
Send your approximate sizes and we'll return a detailed quotation — free, itemised and without obligation.
Free, no-obligation quotes
Send drawings or approximate sizes and receive a detailed quotation within 2–3 working days.
Certified performance
Systems tested to EN standards for air, water and wind, with project U-value reports on request.
Guarantees that last
Lifetime structural warranty on profiles and up to 25 years on powder-coated finishes.
